ARROW PLUS WEDGE ANCHOR (ICC-ES APPROVED)
Features：

Cracked and uncracked concrete seismic and dynamic load applications. Not require precise hole depth or hole cleaning out. Anchor can be hammered below the surface of the concrete when no longer needed. The one piece clip is formed around Anchor, assuring full expansion for dependable, superior holding prower. Expanding clip will not fall off or twist in the hole. The test values listed beneath were obtained using C20-C30 concrete (no aggregate). A safe working load should not exceed 25% of stated values.

Material：

Medium Carbon steel

Application：

Used for equipment, channel steel, guide rail, bracket fixation, external wall, substrate fixation.

PDF

Order Code Anchor Size

Min

Thread Length

Min

Embedment Depth

Max

Thinckness for Fixture

Ultimate Pull Out Load

(Kgf)

Design Pull Out Load

(Kgf)
ARROW PLUS WA14134  1/4x1-3/4 3/4 1-1/8 1/8 900 240
ARROW PLUS WA14214  1/4x2-1/4 1-1/4 3/8
ARROW PLUS WA14300  1/4x3 2 1-1/8
ARROW PLUS WA14314 1/4x3-1/4 2-1/4 1-3/8
ARROW PLUS WA38218 3/8x2-1/8 3/4 1-1/2 1/8 1700 580
ARROW PLUS WA38214 3/8x2-1/4 7/8 3/16
ARROW PLUS WA38234 3/8x2-3/4 1-3/8 3/8
ARROW PLUS WA38300 3/8x3 1-5/8 9/16
ARROW PLUS WA38312 3/8x3-1/2 2-1/8 1
ARROW PLUS WA38334 3/8x3-3/4 2-3/8 1-1/8
ARROW PLUS WA38500 3/8x5 3-5/8 2-3/8
ARROW PLUS WA12234 1/2x2-3/4 7/8 2-1/4 1/8 2600 800
ARROW PLUS WA12334 1/2x3-3/4 1-7/8 11/16
ARROW PLUS WA12414 1/2x4-1/4 2-7/16 3/4
ARROW PLUS WA12512 1/2x5-1/2 3-11/16 2
ARROW PLUS WA12700 1/2x7 4 3-1/8
ARROW PLUS WA58312 5/8x3-1/2 1-3/8 2-3/4 1/8 3800 1200
ARROW PLUS WA58412 5/8x4-1/2 2-3/8 9/16
ARROW PLUS WA58500 5/8x5 2-7/8 1-1/8
ARROW PLUS WA58600 5/8x6 3-7/8 2
ARROW PLUS WA58700 5/8x7 4 3-1/8
ARROW PLUS WA34414 3/4x4-1/4 1-7/8 3-1/4 9/16 5800 1400
ARROW PLUS WA34434 3/4x4-3/4 2-3/8 1
ARROW PLUS WA34512 3/4x5-1/2 3-1/8 1-5/16
ARROW PLUS WA34614 3/4x6-1/4 3-7/8 1-3/4
ARROW PLUS WA34700 3/4x7 4 2
ARROW PLUS WA34812 3/4x8-1/2 4 3-1/8
