ARROW DROP IN ANCHOR (ETA)

Features：

Drop in anchor with ETA approved. Perfect expansion and specially designed built-in plug ensures full expansion of anchor. The test values listed beneath were obtained using C20-C30 concrete (no aggregate) A safe working load should not exceed 25% of stated values.

Material：

Carbon Steel

Application：

Wall, plumbing, air conditioning system, fence, ceiling installation and fixing.

PDF

Order Code	Thread Size (A)	Anchor Dia (B)	Thread Depth (D)	Anchor Length (C)	Pull Out Load (Kgf)	Qty Box/Ctn	Weight kgs per 1000 pcs	Number Setting Tool
ARROW DRM-08	M8 (W5/16)	10	14	30	1350	100/2000	12.5	DMT-08
ARROW DRM-08	M8 (W5/16)	10	14	30	1350	100/2000	12.5	DMT-08
ARROW DRM-10	M10 (W3/8)	12	15	40	1950	50/1000	25.0	DMT-10
ARROW DRM-12	M12 (W1/2)	16	20	50	2900	50/500	51.0	DMT-12
ARROW LIP DR-08	M8 (W5/16)	10	14	30	1350	100/2000	12.5	DMT-08
ARROW LIP DRM-10	M10 (W3/8)	12	15	40	1950	50/1000	25.0	DMT-10
ARROW LIP DRM-12	M12 (W1/2)	16	20	50	2900	50/500	51.0	DMT-12
